An IPTV bearer network requires the broadband TV (BTV), VOD, and near video on demand (NVOD) services. Video programs use the standard MPEG 4 codec format. Which of the following statements about the QoS policy are true?

• A.To ensure the IPTV service quality on the user side, reserve 2.5 Mbit/s bandwidth for the IPTV service for each user and plan extra bandwidth for the broadband Internet service.
• B.Ensure that the VOD/NVOD service has a higher priority than the BTV service and guarantee QoS of both the upstream and downstream traffic.
• C.Ensure that the BTV service has a higher priority than the VOD/NVOD service, and forward the downstream traffic and some protocol packets, such as the IGMP and PIM packets in priority.
• D.To ensure the IPTV service quality on the user side, reserve 4 Mbit/s bandwidth for the IPTV service for each user and plan extra bandwidth for the broadband Internet service.

<Quidway>display current-configuration
#
multicast routing-enable
#
interface Ethernet6/1/0
ip address 10.1.1.1 255.255.255.0
igmp timer query 40
#
igmp
The preceding are partial multicast router configurations. How long is the interval (in seconds) for sending IGMP General Query messages when IGMP is enabled on Ethernet 6/1/0?

• A.10
• B.60
• C.40
• D.15

User A wants to obtain a better network service for business development and signs an SLA with a carrier. User A purchases a bandwidth of 5 Mbit/s to ensure the voice service (requiring short delay), video service, key data services, and other services. If you were the carrier's network administrator, what would you do on the PE to ensure these services?

• A.Mark the VoIP service as EF, set the CIR to 1 Mbit/s, and set the PIR to 1 Mbit/s; mark the video service as AF4, set the CIR to 2 Mbit/s, and set the PIR to 2 Mbit/s; mark key data services as AF1, set the CIR to 2 Mbit/s, and the PIR to 5 Mbit/s; mark other services as BE, set the CIR to 0 Mbit/s, and set PIR to 5 Mbit/s.
• B.Mark the VoIP service as EF and set the CIR and PIR to 2 Mbit/s; mark the video service as AF3 and set the CIR and PIR to 2 Mbit/s; mark key data services as AF4, set the CIR to 2 Mbit/s, and the PIR to 5 Mbit/s; mark other services as BE, set the CIR to 0 Mbit/s, and set PIR to 5 Mbit/s.
• C.Mark the VoIP service as AF4, set the CIR to 0 Mbit/s, and set the PIR to 1 Mbit/s; mark the video service as EF and set the CIR and PIR to 5 Mbit/s; mark key data services as AF3, set the CIR to 2 Mbit/s, and the PIR to 5 Mbit/s; mark other services as BE, set the CIR to 0 Mbit/s, and set PIR to 2 Mbit/s.
• D.Mark the VoIP service as EF, set the CIR to 0 Mbit/s, and set the PIR to 1 Mbit/s; mark the video service as AF4 and set the CIR and PIR to 2 Mbit/s; mark key data services as AF3, set the CIR to 1 Mbit/s, and the PIR to 5 Mbit/s; mark other services as AF1, set the CIR to 2 Mbit/s, and set PIR to 5 Mbit/s.

Which of the following statements describe the reliability requirements of the voice service for the IP bearer network?

• A.The IP network uses a full/half-meshed structure and provides redundant links to strengthen the self-healing capability.
• B.Link protection switching time can larger than 150 ms
• C.Link protection switching time = 50 ms
• D.Key modules of equipment must support active/standby switching or other redundancy backup functions.

Refer to the exhibit.

Which statement about Hub & Spoke MPLS VPN is false?
A . If two Spoke sites are connected to the same Spoke PE, they must be assigned to different VPN instances to prevent them from exchanging routing information.
B . The route of traffic from Spoke site 1 to Hub site 2: Traffic enters Hub site 3 through an interface under VPN1-Hub of the Hub PE and is then forwarded to Spoke site 2 through an interface under VPN1-Spoke of the Hub PE.
C . The route of traffic from Spoke site 2 to Hub site 1: Traffic enters Hub site 3 through an interface under VPN1-Spoke of the Hub PE and is then forwarded to Spoke site 2 through an interface under VPN1-Hub of the Hub PE.
D . The Hub PE can advertise aggregate Spoke site routes or default routes to Spoke PEs through VPNv4.
E .Routes advertised by a Spoke PE to Spoke site 1 of the Hub PE may be advertised back by the Hub PE through a VPNv4 neighbor.
Configure VRFs and relevant policies on a PE as follows:
#
ip vpn-instance vrf1
route-distinguisher 100:1
export route-policy vrf1
vpn-target 1:1 export-extcommunity
vpn-target 2:2 import-extcommunity
ip vpn-instance vrf2
route-distinguisher 100:2
import route-policy vrf2
vpn-target 1:1 3:3 export-extcommunity
vpn-target 1:1 3:3 import-extcommunity
ip vpn-instance vrf3
route-distinguisher 100:3
import route-policy vrf3
vpn-target 2:2 3:3 export-extcommunityvpn-target 2:2 3:3 import-extcommunity ip vpn-instance vrf4 route-distinguisher 100:4 import route-policy vrf4 vpn-target 1:1 export-extcommunity vpn-target 2:2 import-extcommunity
#
route-policy vrf2 deny node 1
if-match extcommunity-filter 1
#
route-policy vrf2 permit node 2
#
route-policy vrf1 permit node 1
apply extcommunity rt 3:3 additive
#
route-policy vrf3 permit node 1
if-match extcommunity-filter 2
#
route-policy vrf4 permit node 1
if-match extcommunity-filter 3
#
ip extcommunity-filter 1 permit rt 2:2
ip extcommunity-filter 2 deny rt 1:1
ip extcommunity-filter 3 permit rt 3:3
#
If a route is imported to the routing table of VRF 1, which VRF can the route match?(A)

• A.vrf3
• B.None
• C.vrf2
• D.vrf4
