Which of the following is correct about packet encapsulation order of L2TP over IPSec?

• A.The sequence from the first encapsulation to the post encapsulation is IPSec>L2TP->UDP->PPP
• B.The sequence from the first encapsulation to the post encapsulation is PPP>L2TP->UDP->IPSec
• C.The sequence from the first encapsulation to the post encapsulation is IPSec>PPP->L2TP->UDP
• D.The sequence from the first encapsulation to the post encapsulation is PPP>UDP->L2TP->IPSec

According to the dual-system hot backup networking diagram, which of the following statements is incorrect regarding the dual-system hot backup preemption function?

• A.By default, preemption function is disabled
• B.The preemption function of the VGMP management group is similar to that of the VRRP backup group. When the fault of a backup group in the management group recovers, the priority of the management group is also restored.
• C.After the VRRP backup group is added to the VGMP management group, the original preemption function on the backup group will become invalid. The preemption behavior must be determined by the VGMP management group.
• D.The VRRP backup group has its own preemption function. As shown in the figure, after USG_A fails and recovers, USG_A uses the preemption function to revert to the master state.

Huawei has the following bandwidth policy configuration command on the USG6000:
[USG] traffic-policy
[USG-policy-traffic] profile class1
[USG-policy-traffic-profile-class1] bandwidth maximum-bandwidth whole both 1000
[USG-policy-traffic-profile-class1] bandwidth connection-limit whole both 20
[USG-policy-traffic-profile-class1] quit
[USG-policy-traffic] rule name policy1
[USG-policy-traffic-rule-policy1] source-zone untrust
[USG-policy-traffic-rule-policy1] destination-zone dmz
[USG-policy-traffic-rule-policy1] destination-address 10.10.10.0 mask 255.255.255.0
[USG-policy-traffic-rule-policy1] action cos profile class1
[USG-policy-traffic-rule-policy1] quit
[USG-policy-traffic] rule name policy2
[USG-policy-traffic-rule-policy2] source -zo ne dmz
[USG-policy-traffic-rule-policy2] destination-zone untrust
[USG-policy-traffic-rule-policy2] destination-address 10.10.10.5 mask 255.255.255.255
[USG-policy-traffic-rule-policy2] action no-qos
Which of the following statements are correct? (Multiple choices)

• A.When accessing a host with a destination address of 10.10.10.5, the number of connections will be limited
• B.When accessing the destination network segment 10.10.10.0/24, it will not be restricted by the maximum number of connections 20
• C.When accessing a host with a destination address of 10.10.10.5 will not be limited by the bandwidth policy
• D.When accessing the destination network segment 10.10.10.0/24, traffic will be limited by a maximum of 20 connections.

The following bandwidth policy configuration commands are available on Huawei's USG6000 products:
[USG] traffic-policy
[USG-policy-traffic] profile class1
[USG-policy-traffic-profile-class1] bandwidth maximum-bandwidth whole both 1000
[USG-policy-traffic-profile-class1] quit
[USG-policy-traffic] rule name policy1
[USG-policy-traffic-rule-policy1] source-zone trust
[USG-policy-traffic-rule-policy1] destination-zone untrust
[USG-policy-traffic-rule-policy1] source-address 192.168.1.0 mask 255.255.255.0
[USG-policy-traffic-rule-policy1] destination-address 192.168.2.0 mask 255.255.255.0
[USG-policy-traffic-rule-policy1] action cos profile class1
Which of the following statements are correct? (Multiple choices)

• A.The traffic matching Policy1 is directly released without restriction
• B.Match the traffic of Policy1 and control the flow of each source IP
• C.Class1 defines the overall current limit and limits the 1000kbps
• D.192.168.1.0/24 hosts will be restricted from accessing 192.168.2.0/24 traffic

After the intelligent routing session holding function is enabled, when an intelligent routing interface is down, all traffic of the interface will be forwarded on other intelligent routing interfaces. What happens when the interface is re-up?

• A.The interface traffic is very slow
• B.The interface cannot participate in intelligent routing
• C.The physical state of the interface is Up and the protocol state is error-down. You need to manually join the intelligent route selection.
• D.The interface cannot forward traffic
