An engineer configures a Cisco ACI Multi-Pod for disaster recovery. Which action should be taken for the new nodes to be discoverable by the existing Cisco APICs?

• A.Enable DHCP relay on all links that are connected to Cisco ACI spines on IPN devices.
• B.Configure BGP as the underlay protocol in IPN.
• C.Enable subinterfaces with dot1q tagging on all links between the IPN routers.
• D.Configure IGMPv3 on the interfaces of IPN routers that face the Cisco ACI spine.

In a Cisco ACI Multi-Site fabric, the Inter-Site BUM Traffic Allow option is enabled in a specific stretched bridge domain. What is used to forward BUM traffic to all endpoints in the same broadcast domain?

• A.egress replication on the destination leaf switches
• B.ingress replication on the spines in the source site
• C.ingress replication on the spines in the destination site
• D.egress replication on the source leaf switches

Cisco ACI fabric is migrated from network-centric mode to application-centric mode. What is possible in an application-centric design?

• A.Cisco ACI VMM integration with hypervisors
• B.remapping of VLAN pools
• C.creation of additional EPGs under one bridge domain
• D.migration of bare metal servers to virtual machines

Refer to the exhibit.

Which two configurations enable inter-VRF communication? (Choose two.)

• A.Change the contract scope to Tenant
• B.Set the subnet scope to Shared Between VRFs
• C.Enable Advertise Externally under the subnet scope
• D.Change the subject scope to VRF
• E.Export the contract and import as a contract interface

Refer to the exhibit.

Which two configuration steps are required in ISN for Cisco ACI Multi-Site setup? (Choose two.)

• A.Configure BIDIR-PIM throughout the ISN
• B.Enable IGMPv3 on ISN routers
• C.Configure OSPF between spines and ISN routers
• D.Increase ISN MTU to support the maximum MTU that is sent by endpoints
• E.Connect Spine2 to ISN routers.
